VS-GW1600 V2 WCDMA Wireless Gateway, an updated product of the VS- GW1600 Series, is now the leading open source Asterisk-based VoIP Gateway easy for SMBs and SOHOs. The VS-GW1600 V2 Wireless Gateway with the Modular Design can provide up to 5 plug-in GSM/WCDMA/LTE gateway modules which could easily from 4 to 20 GSM/WCDMA/LTE channels, developed for interconnecting a wide pick of codecs, include 2G/3G/4G networks to the G.711A, G.711U, G.729, G.722, G.723, G.726 & GSM, to easily reduce telecommunication expenses and maximize cost-budget. With the different designs for VS-GW1600 V2 Wireless Gateway
VS-GW1600 V2 Wireless Gateway Frequency Range | |||||||
Module Type | GSM | WCDMA | LTE | ||||
Band | GSM 850/900/1800/1900MHz | Europe 900/2100MHz @UMTS 900/1800MHz @GSM America 850/1900MHz @UMTS 850/900/1800/1900MHz @GSM Thailand 850/2100MHz @UMTS 850/900/1800/1900MHz @GSM |
China/India LTE FDD: B1/B3/B5/B8 LTE TDD: B38/B39/B40/B41 WCDMA: B1/B8 TD-SCDMA: B34/B39 CDMA: BC0 GSM: 900/1800MHz |
EMEA/Korea/Thailand LTE FDD: B1/B3/B5/B7/B8/B20 LTE TDD: B38/B40/B41 WCDMA: B1/B5/B8 GSM: B3/B8 |
Australia/New Zealand/Taiwan/Brazil LTE FDD: B1/B2/B3/B4/B5/B7/B8/B28 LTE TDD: B40 WCDMA: B1/B2/B5/B8 GSM: B2/B3/B5/B8 |
VS-GW1600 V2 WCDMA Wireless Gateway |
