OpenVox MAG1000 Series Analog Gateway


OpenVox MAG1000 Series Analog VoIP Gateway allows16/24/32 ports of FXO/FXS with the port combination. With the features of exquisite enclosure and high performance, MAG series analog gateways are specially designed to save lots of space and maximize cost savings. It is a superb solution for the industry VoIP analog gateway. It can be configured for different country uses, provides a wide selection of codecs including G.711A、G.711U、G.729、 G.722G.726、ILBC.The MAG Analog VoIP Gateways use standard SIP protocol and fully compatible with Leading IMS/NGNplatform, IPPBX and SIP servers. It has obtained professional CE certification.


  • Simple and convenient configuration via Web GUI
  • Abundant Log Features, Automatically Reboot, Call status display Language selection (Chinese/English)
  • Open API interface(AMI)
  • Support T.38 fax relay and T.30 fax transparent, FSK and DTMF signaling, can continually fax multiple pages
  • Echo cancellation and Static jitter buffer
  • Support DTMF relay
  • Support Ring cadence and frequency setting
  • Support Volume adjustment, Gain adjustment, call transfer, call hold, call waiting, call forward, Caller ID display/li>
  • Three-way calling, Call transfer, Dial-up matching table
  • Support MWI(Message waiting indicator)
  • Support DHCP、DNS/DDNS、NAT networking
  • Support diverse SIP protocols
  • Diverse extensible applications, such as DISA
  • Support NTP time synchronization and client time synchronization
  • Support modify username and password for web login
  • Support SSH remote operation
  • Support add, modify & delete SIP Accounts ,batch add, modify & delete SIP Accounts
  • Support multiple SIP registrations: Anonymous, Endpoint registers with this gateway, This gateway registers with the endpoint
  • SIP accounts can be registered to multiple servers
  • Support update firmware online
  • Support configuration file backup and upload
  • Support for custom scripts, dialplans
  • Support restore the factory settings
  • Network type:Static IP, Dynamic
  • Telnet, HTTP, HTTPS, SSH
  • VPN client
  • Network Toolbox
  • Affordable Price with Superior Performance
  • Compatible with Asterisk, Issabel, 3CX, FreeSWITCH Sip Server and VOS VoIP operating platform
  • Available for OEM
  • 3-Month "No Questions Asked" Return Policy
  • One Year Warranty


Technical Specifications:

Models MAG1000-16 MAG1000-24 MAG1000-32
Ports 16 FXS/FXO ports 24 FXS/FXO ports 32 FXS/FXO ports
Port type RJ11/RJ45/RJ21
Ethernet Ports 2 * 10/100Mbps Ports
Console RJ45
Dimension(bare) 440*45*220mm
Dimension(with packaging) 510*90*310mm
Weight(with packaging) 2.86kg 2.98kg 3.1kg
Maximum Power Consumption 20W 28W 36W
Power Supply 90-264VAC
Operation Temperature 0°C ~ 45°C
Operation Humidity Range 10% ~ 90% NON-CONDENSING
Storage Temperature Range -20°C ~ 70°C
Certification CE

Manual PDF
